Aka Wind steel or steel front, also known as white steel. Means that even if the cooling time of quenching can be cured in air, and very sharp. It is a component of a complex of steel, comprising forming elements tungsten, molybdenum, chromium, vanadium, cobalt carbide. The total amount of alloying elements of about 10 to 25%. It produces fever cases in high-speed cutting (about 500 ℃) still maintain high hardness, HRC can in 60 or more. This is the most important characteristic of high speed steel - red hardness. And the carbon tool steel after quenching and tempering, at room temperature, although the high hardness, but when the temperature is higher than 200 ℃, the hardness will be decreased drastically, 500 ℃ hardness in the annealed condition and has been reduced to a similar extent completely lost the ability to cut the metal, which limits the production of carbon tool steel cutting tools. The high-speed steel due to good red hardness, to make up for the shortcomings deadly carbon tool steel, can be used to manufacture cutting tools.
Grade:
GB9943 | ISO 4957 | JIS | AISI | ERASTEEL | BOHLER |
W2Mo9Cr4VCo8 | HS2-9-1-8 | SKH59 | M42 | EM42 | S500 |
W6Mo5Cr4V2Co5 | HS6-5-2-5 | SKH55 | (M35) | EM35 | S705 |
W7Mo4Cr4V2Co5 | M41 | ||||
W12Cr4V5Co5 | HS12-1-5-5 | SKH10 | T15 | ||
W10Mo4Cr4V3Co10 | HS10-4-3-10 | SKH57 | (T42) | WKE42 | S700 |
W6Mo5Cr4V2Al | S620 | ||||
W6Mo5Cr4V3 | HS6-5-3 | SKH53 | M3-2 | EM3:2 | S607 |
CW6Mo5Cr4V3 | HS6-5-3C | ||||
W6Mo5Cr4V4 | HS6-5-4 | SKH54 | M4 | ||
W6Mo5Cr4V2 | HS6-5-2 | SKH51 | M2 | ||
W6Mo5Cr4V2 | HS6-5-2 | SKH51 | M2 | ||
CW6Mo5Cr4V2 | HS6-5-2C | CM2 | EM2 | S600 | |
W6Mo6Cr4V2 | HS6-6-2 | ||||
(W6Mo3Cr4V2) | |||||
W9Mo3Cr4V | |||||
W2Mo8Cr4V | HS1-8-1 | M1 | |||
W2Mo9Cr4V2 | HS2-9-2 | SKH58 | M7 | EM7 | S400 |
W18Cr4V | HS18-0-1 | SKH2 | T1 | ET1 | S200 |
W1Mo4Cr4V2 | HS1-4-2 | M52 | |||
W4Mo3Cr4VSi | |||||
W3Mo3Cr4V2 | HS3-3-2 | ABCⅢ | |||
(W3Mo2Cr4V2Si) |
Outer Diameter(mm) | Length(mm) | |
Hot rolled | 16-90 | 300-5000 |
Cold drawn | 1-50 | 100-5000 |
Forging | 50-300 | 100-3000 |
Pre hardened | 5-100 | 100-2000(HRC 60-69) |
Depending on your needs |
Surface
Polish |
Pull light |
Black |
Drawing |
Bright |
Bright silver |
Stripping |
Acid White |
Polishing |
